Specialized Oleochemical Facility

Stearin Beading Plant

Advanced spray congealing technology. Designed by Elite Process Technologies to produce highly uniform, free-flowing stearin beads with comprehensive process control.

Proven Track Record

Our Stearin Beading Installations

Delivering precision-engineered spray tower beading units to industry-leading partners.

30 TPD Stearin Beading Plant
30 TPD

Stearin Beading Plant

Elite Natural Oils & Fuels

20 TPD Spray Tower Beading Plant
20 TPD

Spray Tower Beading Plant

Navabharat Limited

The Challenge & Solution

Perfect Solidification. Zero Clumping.

Handling molten palm stearin requires precision. Our process is specifically designed to handle molten stearin as the primary feedstock, converting it into free-flowing beads suitable for packaging, storage, and downstream industrial applications.

Through modern automation, rapid cooling technology, and precision spray atomization, we completely eliminate the common industry issues of bead clumping, irregular sizing, and high dust generation.

Explore Technical Features
Industrial Atomization
System Architecture

The 5-Stage Beading Process

From molten liquid to perfectly classified solid beads, fully automated.

A

Feed Preparation & Storage

Molten palm stearin is precisely heated and maintained at the optimal viscosity required for uniform atomization.

B

Spray Tower Atomization & Cooling

The core stage. Liquid is sprayed through precision nozzles while ascending chilled air instantly congeals the droplets into solid beads.

C

Primary Product Collection & Classification

Solidified beads fall to the tower base and pass through a vibro-sifter screen, separating the product into three distinct size fractions.

D

Dust Recovery

Exhaust air carrying ultra-fine particles passes through dual cyclone separators, ensuring zero emissions and capturing fines.

E

Complete Recycling System

Oversized beads and recovered dust are sent to a remelt tank, continuously recycled back into the feed system for 100% material recovery.

Technical Visualization

Atomization & Congealing

Visualizing the physical state change from hot molten liquid to perfectly uniform solid beads.

Feedstock
Molten Stearin
High-Temp Liquid Phase
Spray Nozzle
+ Glycol Chiller
Rapid Cooling
Final Product
Solid Beads
Cold Solid Phase (600-800µm)

Liquid Phase (Heat)  →  Solid Phase (Chilled Air)

Plant Specifications

Advanced Engineering Features

Our Spray Tower is equipped with cutting-edge components to guarantee efficiency, zero waste, and continuous operation.

Precision Nozzles

Advanced atomization producing uniform 300–1000-micron droplets with minimal fines generation.

Chiller System

Glycol-based cooling circuit maintaining precise chilled air supply for rapid and consistent bead solidification.

Multi-Stage Cooling

Integrated aluminum plate-fin air cooler with powerful FD and ID fan systems for optimal aerodynamics.

Vibro-Assisted Tower

Internal vibration motors actively dislodge powder deposits, preventing internal coating and buildup.

Product Classification

High-efficiency vibro-sifter screens accurately separate the output beads into three distinct size fractions.

Dust Recovery

Dual cyclone separators meticulously capture all airborne fines and dust, ensuring zero emissions.

Continuous Recycling

Remelt tank system with automated recirculation pumps guarantees 100% recovery of off-spec beads.

Process Flexibility

Engineered capability to handle varying stearin specifications, iodine values, and batch compositions seamlessly.
